扩展卡尔曼滤波器

kalman_filter.cpp

#include "kalman_filter.h"


#include <iostream>

using namespace std;

using Eigen::MatrixXd;
using Eigen::VectorXd;

// Please note that the Eigen library does not initialize
// VectorXd or MatrixXd objects with zeros upon creation.
const double PI = 3.1415926535;

KalmanFilter::KalmanFilter() {}

KalmanFilter::~KalmanFilter() {}

void KalmanFilter::Init(VectorXd &x_in, MatrixXd &P_in, MatrixXd &F_in,
                        MatrixXd &H_in, MatrixXd &R_in, MatrixXd &Q_in) {
    x_ = x_in;
    P_ = P_in;
    F_ = F_in;
    H_ = H_in;
    R_ = R_in;
    Q_ = Q_in;
}

void KalmanFilter::Predict() {
    /**
      * predict the state
    */

    x_ = F_ * x_;
    P_ = F_ * P_ * F_.transpose() + Q_;

}

void KalmanFilter::Update(const VectorXd &z) {
    /**
      * update the state by using Kalman Filter equations
    */

    VectorXd y = z - H_ * x_;
    MatrixXd S = H_ * P_ * H_.transpose() + R_;
    MatrixXd K = P_ * H_.transpose() * S.inverse();


    x_ = x_ + (K * y);
    long x_size = x_.size();
    MatrixXd I = MatrixXd::Identity(x_size, x_size);
    P_ = (I - K * H_) * P_;
}

void KalmanFilter::UpdateEKF(const VectorXd &z) {
    /**
      * update the state by using Extended Kalman Filter equations
    */

    double rho = sqrt(x_(0) * x_(0) + x_(1) * x_(1));
    double phi = atan2(x_(1), x_(0));
    double rho_dot;

    if (fabs(rho) < 0.001) {
        rho_dot = (x_(0) * x_(2) + x_(1)*x_(3))/.001;
    } else {
        rho_dot = (x_(0) * x_(2) + x_(1) * x_(3)) / rho;
    }

    VectorXd z_p(3);
    z_p << rho, phi, rho_dot;

    VectorXd y = z - z_p;

    while ((y[1] < -1. * PI) || (y[1] > PI)) {
        if (y[1] < -1. * PI) {
            y[1] += 2. * PI;
        } else {
            y[1] -= 2. * PI;
        }
    }

    MatrixXd S = H_ * P_ * H_.transpose() + R_;
    MatrixXd K = P_ * H_.transpose() * S.inverse();


    x_ = x_ + (K * y);
    long x_size = x_.size();
    MatrixXd I = MatrixXd::Identity(x_size, x_size);
    P_ = (I - K * H_) * P_;

}

FusionEKF.cpp

#include "FusionEKF.h"
#include <iostream>


using namespace std;
using Eigen::MatrixXd;
using Eigen::VectorXd;
using std::vector;

const double PI = 3.1415926535;
Tools tool = Tools();

/*
 * Constructor.
 */
FusionEKF::FusionEKF() {
    is_initialized_ = false;

    previous_timestamp_ = 0;

    // initializing matrices
    R_laser_ = MatrixXd(2, 2);
    R_radar_ = MatrixXd(3, 3);

    H_laser_ = MatrixXd(2, 4);
    Hj_ = MatrixXd(3, 4);

    //measurement covariance matrix - laser
    R_laser_ << 0.0225, 0,
            0, 0.0225;

    //measurement covariance matrix - radar
    R_radar_ << 0.09, 0, 0,
            0, 0.0009, 0,
            0, 0, 0.09;
    /**
      * Finish initializing the FusionEKF.
      * Set the process and measurement noises
    */

    H_laser_ << 1, 0, 0, 0,
            0, 1, 0, 0;

    ekf_.P_ = MatrixXd(4, 4);
    ekf_.P_ << 1, 0, 0, 0,
            0, 1, 0, 0,
            0, 0, 1000, 0,
            0, 0, 0, 1000;


    ekf_.F_ = MatrixXd(4, 4);
    ekf_.F_ << 1, 0, 1, 0,
            0, 1, 0, 1,
            0, 0, 1, 0,
            0, 0, 0, 1;

    ekf_.Q_ = MatrixXd(4, 4);

}

/**
* Destructor.
*/
FusionEKF::~FusionEKF() {}

void FusionEKF::ProcessMeasurement(const MeasurementPackage &measurement_pack) {


    /*****************************************************************************
     *  Initialization
     ****************************************************************************/
    if (!is_initialized_) {
        /**
          * Initialize the state ekf_.x_ with the first measurement.
          * Create the covariance matrix.
          * Remember: you'll need to convert radar from polar to cartesian coordinates.
        */
        // first measurement
        cout << "EKF: " << endl;
        ekf_.x_ = VectorXd(4);
        ekf_.x_ << 1, 1, 1, 1;

        if (measurement_pack.sensor_type_ == MeasurementPackage::RADAR) {
            /**
            Convert radar from polar to cartesian coordinates and initialize state.
            */
            Eigen::VectorXd raw = measurement_pack.raw_measurements_;
            double theta = raw(1);
            double ro = raw(0);
            double ro_dot = raw(2);

            while ((theta < -1. * PI) || (theta > PI)) {
                if (theta < -1. * PI) {
                    theta += 2. * PI;
                } else {
                    theta -= 2. * PI;
                }
            }

            double px = ro * cos(theta);
            double py = ro * sin(theta);
            double vx = ro_dot * cos(theta);
            double vy = ro_dot * sin(theta);

            ekf_.x_ << px, py, vx, vy;
        } else if (measurement_pack.sensor_type_ == MeasurementPackage::LASER) {
            /**
            Initialize state.
            */
            Eigen::VectorXd raw = measurement_pack.raw_measurements_;
            ekf_.x_ << raw(0), raw(1), 0, 0;
        }

        // done initializing, no need to predict or update
        previous_timestamp_ = measurement_pack.timestamp_;
        is_initialized_ = true;
        return;
    }


    /*****************************************************************************
     *  Prediction
     ****************************************************************************/

    /**
       * Update the state transition matrix F according to the new elapsed time.
        - Time is measured in seconds.
       * Update the process noise covariance matrix.
       * Use noise_ax = 9 and noise_ay = 9 for your Q matrix.
     */

    double delta_t = (measurement_pack.timestamp_ - previous_timestamp_) / 1000000.0;
    previous_timestamp_ = measurement_pack.timestamp_;
    ekf_.F_ << 1, 0, delta_t, 0,
            0, 1, 0, delta_t,
            0, 0, 1, 0,
            0, 0, 0, 1;

    double dt_2 = delta_t * delta_t;
    double dt_3 = dt_2 * delta_t;
    double dt_4 = dt_3 * delta_t;

    double noise_ax = 9;
    double noise_ay = 9;

    ekf_.Q_ << dt_4 / 4 * noise_ax, 0, dt_3 / 2 * noise_ax, 0,
            0, dt_4 / 4 * noise_ay, 0, dt_3 / 2 * noise_ay,
            dt_3 / 2 * noise_ax, 0, dt_2 * noise_ax, 0,
            0, dt_3 / 2 * noise_ay, 0, dt_2 * noise_ay;

    ekf_.Predict();

    /*****************************************************************************
     *  Update
     ****************************************************************************/

    /**
       * Use the sensor type to perform the update step.
       * Update the state and covariance matrices.
     */

    if (measurement_pack.sensor_type_ == MeasurementPackage::RADAR) {
        // Radar updates
        ekf_.R_ = R_radar_;
        Hj_ = tool.CalculateJacobian(ekf_.x_);
        ekf_.H_ = Hj_;
        ekf_.UpdateEKF(measurement_pack.raw_measurements_);
    } else {
        // Laser updates
        ekf_.R_ = R_laser_;
        ekf_.H_ = H_laser_;
        ekf_.Update(measurement_pack.raw_measurements_);
    }

    // print the output
   cout << "x_ = " << ekf_.x_ << endl;
   cout << "P_ = " << ekf_.P_ << endl;
}

Tools.cpp

#include <iostream>
#include "tools.h"

using Eigen::VectorXd;
using Eigen::MatrixXd;
using std::vector;

Tools::Tools() {}

Tools::~Tools() {}

VectorXd Tools::CalculateRMSE(const vector<VectorXd> &estimations,
                              const vector<VectorXd> &ground_truth) {
  VectorXd rmse(4);
  rmse << 0,0,0,0;

  //Check validation
  if (estimations.size() != ground_truth.size() || estimations.size() == 0) {
    cout << "Invalid data. Different size." << endl;
    return rmse;
  }

  //accumulate squared residuals

  for (int i = 0; i < estimations.size(); ++i) {
    VectorXd residual = estimations[i] - ground_truth[i];

    //coefficient-wise multiplication
    residual = residual.array() * residual.array();
    rmse += residual;
  }

  //calculate the mean
  rmse = rmse / estimations.size();

  //calculate the square root
  rmse = rmse.array().sqrt();

  return rmse;

}

MatrixXd Tools::CalculateJacobian(const VectorXd& x_state) {
  MatrixXd Hj(3,4);

  //recover state matrix

  double px = x_state(0);
  double py = x_state(1);
  double vx = x_state(2);
  double vy = x_state(3);

  // pre-compute a set of terms to avoid repeated calculation
  double c1 = px*px + py*py;
  double c2 = sqrt(c1);
  double c3 = (c1*c2);

  //check division by zero
  if (fabs(c1) < 0.0001) {
    cout << "CalculateJacobian() -ERROR- Division by zero" << endl;
    return Hj;
  }

  //compute the Jacobian matrix
  Hj << (px/c2), (py/c2), 0, 0,
          -(py/c1), (px/c1), 0, 0,
          py*(vx*py - vy*px)/c3, px*(px*vy - py*vx)/c3, px/c2, py/c2;

  return Hj;
}
